Disassembly/Assembly Disassembly/Assembly Procedures 11
Epson Stylus NX125/T13/NX130 series Revision F
1.2.1 Standard Operation Time for servicing the product
The following are the standard operation time for servicing the product. Those are based on the MTTR result
measured using a prototype.
The underlined parts/units are supplied as After Service Parts.

Standard Operation Time for servicing NX125/NX130 series :See Table 1-2.
 Standard Operation Time for servicing T13 series:: :::: :See Table 1-3.
Table 1-2. Standard Operation Time (NX125/NX130 series)
Parts/Unit
Time (second)
Parts/Unit
Time (second)
Replace-
ment
Adjust-
ment
Total
Replace-
ment
Adjust-
ment
Total
Panel Unit
14519Printhead 364 1027 1391
Panel Board
29 5 34 Holder Contact Assy 179 1027 1206
Paper Support Assy 12 5 17 CSIC Terminal
221 1027 1248
Paper Support Tray
20 5 25 CR Contact Module 194 1027 1221
Paper Support Tray 2
26 5 31 Holder Contact 293 1027 1320
Stacker Assy 12 5 17 EJ Frame Assy 149 5 154
Tray Exit Inner
15 5 20 EJ Roller 170 768 938
Tray Exit Outer
18523EJ Roller Gear 134 768 902
Jam Cover
18523
Waste Ink Pads (for
flushing)
230 768 998
Document Cover
9 5 14 Cover Flushing 195 768 963
Document Pad
20525
Porous Pad Front Paper
Guide
159 5 164
ASF Cover
5 5 10 CR Motor 235 768 1003
Ink Cartridge Cover
18 5 23 Power Supply Unit 129 768 897
Rear Cover
10 5 15 Waste Ink Tray Assy 163 822 985
Scanner Unit
79 5 84 Waste Ink Pads 239 822 1061
CIS
245 5 250 Main Frame 501 768 1269
Middle Housing Assy 126 5 131 Carriage Assy 906 768 1674
Middle Housing
146 5 151 PCB Encoder 953 768 1721
USB Cover
146 5 151 Head FFC 939 768 1707
LD Roller Assy
186 768 954 Timing Belt 915 768 1683
LD Roller
227 768 995 Carriage 995 768 1763
Housing Buckler
183 5 188 Upper Paper Guide 269 768 1037
Roller Idler Pick Assy 160 5 165 Pump Assy 791 768 1559
CR Scale 181 5 186 Gear Pump Idle
797 768 1565
Main Board
150 1027 1177 Lever Pick Clutch 798 768 1566
Driven Pulley Assy 363 768 1131 Gear Pump
811 768 1579
Pick Assy 376 768 1144 Bracket Pump
832 768 1600
Cap Unit 481 768 1249 Roller Pump
827 768 1595
Lever Cleaner 175 768 943 Waste Ink Tube
892 768 1640
Cap Assy
449 768 1217 Pump Housing 892 768 1660

Epson Stylus S22 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Number of print cartridges	4
Maximum print size	210 x 297 mm
Paper tray media types	Envelopes, Glossy paper, Photo paper, Plain paper
Paper tray media weight	0 - 75 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Photo paper sizes (imperial)	10x15 \
Maximum ISO A-series paper size	A4
Maximum resolution	5760 x 1440 DPI
Print speed (black, normal quality, A4/US Letter)	28 ppm
Print speed (color, normal quality, A4/US Letter)	15 ppm
Printing noise level	42 dB
Total input capacity	100 sheets
Total output capacity	- sheets
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	1.2 W
Power consumption (printing)	10.1 W
Sustainability certificates	ENERGY STAR
Compatible operating systems	Windows XP Windows Vista Windows 7 Mac 10.4.11 +
Country of origin	Thailand
Market positioning	Home & office
Pallet width	800 mm
Pallet height	2150 mm
Pallet length	1200 mm
Pallet width (UK)	1000 mm
Quantity per pallet	60 pc(s)
Quantity per pallet (UK)	80 pc(s)
Quantity per pallet layer	6 pc(s)
Quantity per pallet layer (UK)	8 pc(s)
Package depth	470 mm
Package width	295 mm
Package height	200 mm
Package weight	3400 g
Quantity per pack	1 pc(s)

Weight and Dimensions

Depth	227 mm
Width	415 mm
Height	135 mm
Weight	2400 g
