Confidential
Disassembly/Assembly Overview 9
Epson Stylus NX125/T13/NX130 series Revision F
1.1 Overview
This chapter describes procedures for disassembling the main components of NX125, T13 and NX130 series.
Unless otherwise specified, disassembled units or components can be reassembled by reversing the disassembly
procedure. Refer to " 1.3 Details of Disassembling/Assembling by Parts/Unit (p16)" for cautions and such if
necessary when disassembling and assembling.
Read the " Safety Precautions (p3)" before disassembling and assembling.
When you have to remove components or parts that are not described in this chapter, see the exploded diagrams
of SPI (Service Parts Information).
1.1.1 Tools
Use only specified tools to avoid damaging the printer.
Note *: All of the tools listed above are commercially available.
EPSON provides the tools listed with EPSON part code.
In this chapter, the product names are called as follows:
NX125 series: Epson Stylus NX125/NX127/TX120/TX125/TX123/SX125/TX121/TX121x/
TX129/Epson ME 320/ME 330/ME 350
T13 series: Epson Stylus T13/T13x/T12/N10/N11/T22/T25/S22/T22E/Epson ME 10/
ME 32/ME 33/ME 35
NX130 series: Epson Stylus NX130/TX130/TX133/TX135/SX130/Epson ME 340
Table 1-1. Tools
Name EPSON Part Code*
(+) Phillips screwdriver #1 1080530
(+) Phillips screwdriver #2 ---
Flathead screwdriver ---
Flathead Precision screwdriver #1 ---
Tweezers ---
Longnose pliers ---
Acetate tape 1003963
Nippers ---
