Confidential
Disassembly/Reassembly Overview 25
Epson Stylus SX230 series / SX235W series / SX430W series / SX440W series Revision B
EJ Roller Gear 2:45 --- 2:45
EJ Roller
3:27 4:10 7:37
Hinge 1:49 --- 1:49
Housing Right
2:03 --- 2:03
Cap Assy
3:03 --- 3:03
Cap Lever 3:19 --- 3:19
Porous Pad for Cap Assy 3:10 --- 3:10
Panel Unit
4:19 --- 4:19
Panel Housing Lower Assy 5:12 --- 5:12
Panel Board Assy 5:41 --- 5:41
Panel Board 5:44 --- 5:44
LCD 5:48 --- 5:48
Panel Buttons 6:18 --- 6:18
Panel Housing Upper Assy 6:18 --- 6:18
CR Scale
3:53 --- 3:53
Hopper
3:53 5:28 9:21
LD Roller Cover 3:50 --- 3:50
LD Roller Assy
4:24 0:44 5:08
FFC Holder MB 4:17 --- 4:17
Shield Plate 7:04 --- 7:04
CR Motor
7:52 0:31 8:23
PE Sensor Lever
8:34 0:44 9:18
Main Board
EEPROM Data copy OK 7:45 1:29 9:14
EEPROM Data copy NG 7:45 16:37 24:22
CR Driven Pulley 3:44 1:00 4:44
Main Frame Assy 8:02 12:35 20:37
Paper Guide Upper Assy
14:08 8:31 22:39
CR Unit
12:47 9:47 22:34
CR Timing Belt 13:01 1:00 14:01
CR Encoder Sensor 13:08 --- 13:08
FFC Holder 13:15 --- 13:15
Head FFC
13:15 --- 13:15
Frame Base Assy 8:02 10:38 18:40
Pump Unit 9:48 --- 9:48
PF Grounding Spring 9:56 --- 9:56
Spur Gear 16.5 9:58 --- 9:58
PF Roller Unit 10:30 6:10 16:40
PF Motor Assy 11:10 1:27 12:37
Frame Base 11:10 7:28 18:38
Table 2-1. Standard Operation Time
Parts/Unit
Time (mm:ss)
Replacement
Adjustment/
inspection
Total
