28 | Loading Roll Paper
4. If necessary, adjust the roll media adapters to fit the core size of the roll paper.
5. Release the tension lever on both adapters.
6. Push the adapters into the paper core at both ends of the roll. Press the adapters in until they are fully
inserted into the roll.
7. Push down the tension lever on both adapters to secure them.
3-inch core
2-inch core
3-inch
2-inch
T-Series_Setup_Guide_S.book Page 28 Tuesday, September 16, 2014 2:53 PM
