Epson TM-H6000II User Manual

viii
DIP Switch Tables
Serial
SW Function ON OFF
1-1 Data receive error Ignored Prints “?”
1-2 Receive buffer
capacity
45 bytes 4 KB
1-3 Handshaking XON/XOFF DTR/DSR
1-4 Data word length 7 bits 8 bits
1-5 Parity check Enabled Disabled
1-6 Parity selection Even Odd
1-7
1-8
Transmission speed (See table below.)
2-1 Handshaking
(BUSY condition)
Receive
buffer full
Offline or Receive
buffer full
2-2 Customer display
connection
Connected Not connected
2-3
2-4
Print density See Table A.
2-5
2-6
Internal use. Fixed to Off.
2-7 I/F pin 6 reset Enabled Disabled
2-8 I/F pin 25 reset Enabled Disabled
SW Transmission speed (bps)-bits per second
4800 9600 19200 38400
1-7 ON OFF ON OFF
1-8 ON ON OFF OFF
USB (UB-U05)/Parallel
SW Function ON OFF
1-1
Auto line feed Always
enabled
Always disabled
1-2
Receive buffer
capacity
45 bytes 4 KB
1-3~
1-8
Reserved. Fixed to Off.
2-1
Handshaking
(BUSY condition)
Receive
buffer full
Offline or Receive
buffer full
2-2
USB: Customer
display connection
Connected Not connected
Parallel: Internal use. Do not change setting. Fixed to
Off.
2-3
2-4
Print density See Table A.
2-5
2-6
Internal use. Fixed to Off.
2-7
Reserved (for serial interface) Fixed to Off.
2-8
USB: Fixed to Off.
Parallel:
I/F pin 31 reset signal. Do not change setting. Fixed to On.
Table A
Print density/low power SW 2-3 SW 2-4
1 Print density (Light) ON ON
2OFFOFF
3ONOFF
4 Print density (Dark) OFF ON
TM-H6000II Specifications
Print method Receipt: Thermal line, 180 dpi  180 dpi
Slip: 9-pin serial impact dot matrix
Endorsement: 8-pin shuttle impact dot matrix
(dpi: dots per inch [number of dots per 25.4 mm {1"}])
Print font Receipt: 12  24/9  17
Slip: 5  9/7  9
Endorsement: 5  7
Columns Receipt (Standard): 42/56
Slip: 45/60
Endorsement: 40
Character size
(W  H)
Receipt: 1.41  3.39 mm {0.06  0.13"}
0.99  2.40 mm {0.04  0.09"}
Slip: 1.56  3.1 mm {0.06  0.12"}
1.24  3.1 mm {0.05  0.12"}
Endorsement: 1.1  2.42 mm {0.04  0.10"}
Character sets 95 alphanumeric, 37 international characters
128  11 (slip: 12) graphic
