ix
English
Print speed Receipt:
Normal: Max.: 170 mm/s {approx. 6.7"}
Ladder bar code/2-dimensional code printing:
Max.: 114 mm/s {approx. 4.5"}
Two-color printing: Maximum: 75 mm/s {approx. 3.0"}
Slip: Approx. 5.14 lps
Endorsement: Approx. 1.9 lps
(lps: lines per second)
Paper dimensions Receipt: Thermal roll paper 79.5 ± 0.5 83 mm {3.13 ± 0.02 3.27"}
Slip/endorsement: 68 ~ 230 68 ~ 297 mm {2.7 ~ 9.1 2.7 ~ 11.7"} (W L)
Note: the minimum size is 68 152 mm {2.7 ~ 6.0"}
Paper thickness Slip (single-ply): 0.09 ~ 0.2 mm {0.0035 ~ 0.0079"}
Endorsement: 0.09 ~ 0.2 mm {0.0035 ~ 0.0079"}
Copy capability Receipt/Endorsement: Single-ply
Slip: 1 original + 3 copies
Thermal paper type Monochrome: specified: Nakagawa Mfg. Co., Ltd.: NTP080-80,
[Original: TF50KS-E: Nippon Paper Industries Co., Ltd.]
The following paper can be used instead of the specified paper:
Original: PD 160R: Oji Paper Mfg. Co., Ltd.
Original: AF50KS-E: Jujo Thermal Oy (Finland)
Original: P350 (F380), P310, P300: Kanzaki Specialty Papers, Inc. (U.S.A.)
Two-color: specified: Nakagawa Mfg. Co., Ltd.:ENTPB080080
[Original: PD750R (paper thickness: 75 µm): Oji Paper Mfg. Co., Ltd.]
Inked ribbon Slip: ERC-32 Endorsement: ERC-41
Ribbon life Slip: 4 million characters
Endorsement: 800,000 characters
Interface (compatible) USB/RS-232/IEEE 1284 Bidirectional Parallel
Data buffer Selectable for 45 bytes or 4 KB using DIP switch
D.K.D. function 2 drives
Power supply DC +24 V 10%
Current consumption Slip: Approximately 1.7 A (mean)
Receipt: Approximately 1.9 A (mean)
Temperature Operating: 5 to 45°C {41 to 113°F}
Storage: 10 to 50°C {14 to 122°F}
Humidity Operating: 10 to 90% RH
Storage: 10 to 90% RH
Reliability Receipt: Life mechanism: 15,000,000 lines (when using single-color thermal
paper), 7,500,000 lines (when using two-color thermal paper), MTBF:
360,000 hours, MCBF: 52 million lines, Thermal head life: 100 million pulses,
100 km (when using single-color thermal paper), 50 km (when using two-
color thermal paper), Autocutter life: 1,500,000 cuts
Slip: Life: when the printer is used with MICR and performs printing on both
sides: 7,500,000 lines, MTBF: 180,000 hours
MCBF: 18 million lines (when the printer is used with the MICR and
performs both-sided printing), Print head: 200 million characters, MICR
reader mechanism: 240,000 passes, Image scanner mechanism: 240,000
passes
Card: Image scanner mechanism: 240,000 passes
Endorsement: Life mechanism: 1,350,000 lines, MTBF: 180,000 hours, MCBF:
3,300,000 lines
Overall dimensions 185 186 298 mm {7.28 7.32 11.73"} (H W D)
With the card image scanner:
209 186 298 mm {8.23
7.32 11.73"} (H W D)
Mass Approximately 6.2 kg {13.7 lb}
With the card image scanner: 6.5 kg { 14.3 lb}
TM-H6000II Specifications
