Media specifications
Roll paper specified thermal paper
Take-up width 80 + 0.5/-1.0 mm {3.15 + 0.02/- 0.04 in}
Paper width 79.5 ± 0.5 mm {3.13 ± 0.02 in}
Diameter 83 mm {3.27"} maximum
Core Inside: 12 mm {0.47"}
Outside: 18 mm {0.71"}
Width: equal to paper width or 1 mm less
than paper width
Cut-sheet paper Single ply only.
Height 2.36" to 4.72" {60 to 120 mm}
Length 4.72" to 9.25" {120 to 235 mm}
Thickness 0.003" to 0.008" {0.075 to 0.2 mm}
Weight 16 to 32 lb {60 to 120 g/m
2
}
ID cards ISO/IEC7810-compliant
Height 2.12 to 2.13" {53.92 to 54.18 mm}
Length 3.37 to 3.38" {85.47 to 85.90 mm}
Thickness 0.02 to 0.033” {0.5 to 0.84 mm}
Warpage ≤ 0.079" {2 mm}
MSR cards ISO/IEC7810-compliant
Height 2.12 to 2.13" {53.92 to 54.18 mm}
Length 3.37 to 3.38" {85.47 to 85.90 mm}
Thickness 0.03 to 0.033” {0.76 to 0.84 mm}
Warpage ≤ 0.059" {1.5 mm}
Print specifications
Roll paper printing
Print method: thermal line printing
Dot density: 180 dpi × 180 dpi
(dpi = dots per inch [25.4 mm])
Print width: 2.83" (72 mm), 512 dots
Characters per line:font A: 42
font B: 56
Character structure:font A: 12 × 24 (including 2 dots)
font B: 9 × 17 (including 2 dots)
Character spacing: 0.01" (0.28 mm), 2 dots
programmable by control command
Print direction: unidirectional with friction feed
Print speeds: text printing (with embedded fonts):
11.81"/sec. [300 mm/sec.];
70.9 lps maximum at 1/6" feed
page mode printing:
11.81"/sec. [300 mm/sec.]
graphics printing (monochrome):
11.81"/sec. [300 mm/sec.]
ladder bar code, two-dimensional
symbol printing:
4.8"/sec. [124 mm/sec.]
graphics printing (multi-tone):
5.91"/sec. [155 mm/sec.]
(NV/download graphics);
2.76"/sec. [70 mm/sec.]
(raster graphics)
Paper feed speed: approx. 7.87"/sec. [200 mm/sec.]
(continuous paper feeding)
Cut sheet paper printing
Print method Ink-jet printed line.
Nozzles 360 in 2 lines.
Dot density 180 × 180 dpi.
Print color Black.
Print direction Fixed stroke control.
Print height 2" {50.8 mm}.
Lines printable 12 maximum with font A.
16 maximum with font B.
Line spacing 1/6" default {4.23 mm}.
Programmable by command.
Print width 3.94 to 8.46" {100 to 215 mm}, depending
on paper length.
Paper types Manufacturer information
Specified roll
paper type
NTP080-80 [Original paper: TF50KS-E (Nippon Paper
Industries Co., Ltd.)]
In Japan: Nakagawa Manufacturing Co., Ltd.
In U.S.A.: Nakagawa Mfg. (USA) Inc.
In Europe: Nakagawa Mfg. (Europe) GmbH
In Southeast Asia: N.A.K. Mfg. (Malaysia) SDN BHD
Specified
original paper
type
TF50KS-E, TF60KS-E (NIPPON Paper Industries Co., Ltd.)
PD150R, PD160R, PD190R (OJI Paper Mfg. Co., Ltd.)
P220AGB-1 (Mitsubishi Paper Mills Limited.)
P30023, P31023, P35023 (Kanz
aki specialty Papers)
AF50KS-E (Jujo Thermal Oy)
F5041 (Mutsubishi HiTec)
KT55F20, KT48F20 (Koehler Paper Group)
