18
Specifications
*: Based on Epson operating conditions.
Item
Specification
Printing method
Thermal line printing
Roll paper dimensions Paper width
79.5 mm ± 0.5 mm {3.13" ± 0.02"}
Diameter
83 mm {3.27"} maximum
Inside diameter of core
12 mm {0.47"}
Outside diameter of core
18 mm {0.71"}
Thermal paper type
NTP080-80
Interface
Serial
× 1
RS-232
Parallel
× 1
IEEE1284
USB
× 1
Compliance: USB 2.0
Communication speed: Full-speed (12 Mbps)
Drawer kick
× 1
Current consumption
1.8 A
AC power consumption Operating
*
230 V/50 Hz: 26.4 W
115 V/60 Hz: 26.6 W
Standby
230 V/50 Hz: 0.83 W
115 V/60 Hz: 0.73 W
Temperature
Operating
5 to 45°C {41 to 113°F}
Storage
–10 to 50°C {14 to 122°F}, except for paper
Humidity
Operating
10 to 90% RH
Storage
10 to 90% RH
Overall dimensions
140 × 199 × 146mm {5.51 × 7.83 × 5.75"} (W × D × H)
Weight (mass)
Approx. 1.7 kg {3.74 lb}
