TM-T88III User’s Manual 5
English
Attaching and Removing the Connector Cover
These instructions apply if a connector cover is packed with your
printer to protect your cables. To attach it, follow the steps below:
1. First, connect all the cables. The connector
cover has three possible cable exits: on the
right, left, and back. Remove the tab for the
exit you want to use by breaking it off with
your fingers. See the illustration on the right.
Note:
Once you remove a tab, you cannot replace it.
2. After removing the tab, also remove any protruding plastic, so
that the edge is smooth and does not damage the cables.
3. Position the two hooks on the connector cover so that they
hook the printer case, as shown on the left below.
4. Push the connector cover down to click onto the printer case.
To remove the connector cover, turn the printer over, insert a
flathead screwdriver under one hook, and pry up the hook while
lifting the connector cover. See the illustration on the right below.
Repeat this step for the other side.
Note:
Be careful not to damage the cables with the screwdriver.
Installing the Paper Roll
1. Press the button, as shown on the left below, to open the cover.
2. Remove any used paper roll core, and insert the paper roll as
shown in the center below.
hook
bottom of
the printer
screwdriver
