Epson TM-U675 Installation Guide

5. Attach the paper roll guide as shown below. Be sure that
the rectangular hole in the guide fits over the tab on the
printer. Push the guide until you feel it click into place.
6. Install a paper roll; then close the cover.
Printed in China
1999.10
tab
paper roll
guide

Epson TM-U675 Specifications

General

Color	No
Maximum number of copies	2 copies
Maximum printing width (columns)	60
Mean time between failures (MTBF)	180000 h
Safety	UL, CSA
Certification	VCCI A, FCC A, CE
Standard interfaces	Parallel, RS-485, Serial, USB 2.0
Fonts included	5 × 9 / 7 × 9
Print technology	Dot matrix
Weight (imperial)	10.6 lbs
Dimensions (WxDxH)	186 x 298 x 195 mm
Power requirements	24 V DC ± 10%
Connectivity technology	Wired
Printing media thickness	0.06/0.085 µm
Dimensions (W x D x H) (imperial)	7.3 x 11.7 x 7.7 \
