Confidential
Disassembly/Reassembly Overview 23
WF-2540 / WF-2530 / WF-2520 / WF-2510 / WF-2010 series Revision B
Figure 2-5. Printer Mechanism: Left
Figure 2-6. Printer Mechanism: Rear
No. Name No. Name
1 FAX Assy (p31) (FAX function compatible model) 5 PF Motor Assy (p38)
2
Wireless LAN Module (p34) (Wireless LAN function
compatible model)
6
PF Timingbelt (p34)
3 EJ Roller (p31) 7 PF Scale (p34)
4
Ethernet Board Assy (p31)
(Ethernet function compatible function)
8 PF Encoder Sensor (p34)
9 EJ Roller Gear (p34)
10 USB Board (p31) (USB function compatible model)
No. Name No. Name
1 CR Motor (p34) 4 Waste Ink Pad Assy (p30)
2 Head FFC (p38) 5 PE Sensor Lever (p34)
3 Main Board (p34) 6 PS Unit (p34)
2
3
9
5 7 8
1
4 6
10
1
2
3
5 64
