Troubleshooting 15
Epson WF-5690/4640/4630/5620/5190/5110 series Revision D
ADF/
Scanner
0x30 Option error • Main Board failure
0x36 Paper jam error
• Paper jam
• Foreign object
0x41 FB PID excess speed error
• ADF Encoder failure (contaminated/detached scale, Encoder Board
failure)
• Motor driver failure (Main Board failure)
0x42 FB PID reverse error
• ADF Encoder failure (contaminated/detached scale, Encoder Board
failure)
• Paper jam
0x43 FB PID lock error • ADF Encoder failure (contaminated/detached scale, Encoder Board
failure)
• ADF Motor failure
• ADF drive mechanism overload (assembling failure, lubrication failure)
• Cable disconnection
0x44 FB PID acceleration lock
0x45 FB PID excess load error
0x46 FB PID driving time error • Main Board failure
0x49 FB BS+ excess sped error
• ADF Encoder failure (contaminated/detached scale, Encoder Board
failure)
• Motor driver failure (Main Board failure)
0x4A FB BS+ reverse error
• ADF Encoder failure (contaminated/detached scale, Encoder Board
failure)
0x4B FB BS+ lock error • ADF Encoder failure (contaminated/detached scale, Encoder Board
failure)
• ADF Motor failure
• ADF drive mechanism overload (assembling failure, lubrication failure)
• Cable disconnection
0x4D FB BS+ excess load error
0x4E FB BS+ driving time error • Main Board failure
0x51 Automatic judgement fatal error 1
---*
0x52 Automatic judgement fatal error 2
0x53 Automatic judgement fatal error 3
0x54 Automatic judgement fatal error 4
0x55 Automatic judgement fatal error 5
PDL 0x5F Main ROM and μSD ROM matching error • Mismatch the Main ROM FW version and μSD ROM FW version.
Printer
0x60 HP error
• Paper jam
• Foreign object
• Deformation of the Main Frame
0x61 Deadlock avoidance error
0x62 Impossible contact detection error
0x6B PF runaway error
• PF Encoder failure (contaminated/detached scale, Encoder Board failure)
• Motor drive error
0x7F Inspection mode error ---*
0x8D Factor error other than printer device
This error occurs if the printer becomes a fatal error status due to a failure of
parts other than the printer such as the scanner or ADF
0x8E Driver mismatch error An unsupported driver was used.
0x8F EEPROM verify error (by command) ---*
0x90 PW Sensor failure error • PW sensor failure
• Main Board failure
• Foreign object
0x91 PW Sensor detected foreign object error
0x92 Hot plug disconnection paper jam error
• 2nd Cassette Unit has been removed during feeding (when the ASF
Motor is operating).
• Contact failure of the connector which contacts 2nd Cassette Unit and the
printer.
0x93 PE Sensor error
• PE Sensor failure
• Main Board failure
Table 1-2. Fatal Error List
Error type
Error
code
Error name Possible cause
To Next Page
