Disassembly/Reassembly Disassembly/Reassembly Procedures 30
Epson WF-5690/4640/4630/5620/5190/5110 series Revision D
2.2.3 Disassembly Flowchart
This section describes procedures for disassembling the parts/units in a flowchart format. For some parts/units,
detailed procedures or precautions are provided (accordingly indicated by icons and cell's color). Refer to the
explanations in the example chart below and perform an appropriate disassembling and assembling procedure.
(See "2.3 Detailed Disassembly/Reassembly Procedure for each Part/Unit (p38)".)
For routing cables, see "2.4 Routing FFCs/Cables (p46)".
2.2.3.1 Parts/Units whose Configuration is Different between Models in the Flowchart
The models describe in this manual employ the same printer mechanism but they have different printing related
functions and structures. Therefore, the parts/units vary and the shape of them differs even they have the same
parts name.
In the flowchart in this section, the parts are in two colors: black for the common parts or units, and blue for the
parts or units which differ between models. For the parts or units which differ between models, confirm the
composition of the parts for the printer whose disassembly procedure you want to check, and then see the
disassembly flowchart.
Note: The 2nd Cassette Unit is installed for WF-4640 series, and option for WF-5690/4630/5620/5190/5110 series.
Table 2-3. Parts/Units whose Configuration is Different between Models
Model Name Exterior Parts
Main Board
Related Parts
Control Panel
Components
WF-5690/4640/4630/
5620 series
 "Scanner Unit (p33)"
 "ADF Unit (p33)"
 "ADF Cover Assy (p33)"
• "ADF Cover Housing
Upper (p33)"
• "LD Cover (p33)"
• "LD Shaft (p33)"
• "Extension Spring 0.99
(p33)"
• "ADF LD Assy (p33)"
 "ADF Rear Cover (p33)"
 "ADF Document Support
Assy (p33)"
 "ADF Pad Assy (p32)"
 "FAX Cover (p32)"
 "Interface Board Assy
(p35)"
 "Interface Board Shield
Plate Upper (p35)"
 "Interface Board (p35)"
 "Interface Board Shield
Plate Lower (p35)"
 "Panel Assy (p32)"
WF-5190/5110 series  "Housing Upper Assy (p32)"
 "USB Cover (p32)"
---
 "Panel Assy (p32)"

Epson WF-4640 Series Specifications

General

Max Print Resolution	4800 x 1200 dpi
Automatic Duplex Printing	Yes
Scanner Type	Color flatbed / ADF
Max Scan Resolution	1200 x 2400 dpi
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct, NFC
Functions	Print, Copy, Scan, Fax
Mobile Printing	Epson Connect, Apple AirPrint, Google Cloud Print
Ink Type	DURABrite Ultra pigment ink
OS Compatibility	Windows, Mac
Print Technology	Inkjet
Print Speed (ISO)	20 ppm (black), 20 ppm (color)
Paper Capacity	80 sheets rear feed
Display	color touchscreen
Weight	31.3 lbs
