Troubleshooting 17
Epson WF-5690/4640/4630/5620/5190/5110 series Revision D
Printer
0xDA ASF load position excess load error
• ASF Encoder failure (contaminated/detached scale, Encoder Board
failure)
• ASF Motor failure
• Pickup Roller (2nd cassette) driven mechanism overload (paper jam/
foreign object)
• Cable disconnection
0xDE ASF PID driving time error
• Main Board failure
0xDF ASF load position driving time error
0xE1 CR PID excess load error
• CR Encoder failure (contaminated/detached scale, Encoder board failure)
• CR Motor failure
• Carriage overload error (paper jam/foreign object)
• Cable disconnection
0xE2 CR PID excess speed error
• CR Encoder failure (contaminated/detached scale, Encoder board failure)
• Motor driver failure (Main Board failure)
• Tooth skip of the CR Timing Belt
• Improper tension of the CR Timing Belt
0xE3 CR PID reverse error
• CR Encoder failure (contaminated/detached scale, Encoder board failure)
• Tooth skip of the CR Timing Belt
• Improper tension of the CR Timing Belt
• Paper jam
0xE4 CR PID lock error
• CR Encoder failure (contaminated/detached scale, Encoder Board failure)
• CR Motor failure
• Carriage overload error (paper jam/foreign object)
• Cable disconnection
0xE5 CR PID speed fall error
• CR Encoder failure (contaminated/detached scale, Encoder Board failure)
• Motor driver failure (Main Board failure)
• Tooth skip of the CR Timing Belt
• Improper tension of the CR Timing Belt
• Paper jam
0xE8 CR load position reverse error
• CR Encoder failure (contaminated/detached scale, Encoder Board failure)
• Tooth skip of the CR Timing Belt
• Improper tension of the CR Timing Belt
• Paper jam
0xE9 CR load position excess speed error
• CR Encoder failure (contaminated/detached scale, Encoder Board failure)
• Motor driver failure (Main Board failure)
• Tooth skip of the CR Timing Belt
• Improper tension of the CR Timing Belt
0xEA CR load position excess load error
• CR Encoder failure (contaminated/detached scale, Encoder Board failure)
• CR Motor failure
• Carriage overload error (paper jam/foreign object)
• Cable disconnection
0xEE CR PID driving time error
• Main Board failure
0xEF CR load position driving time error
0xF1 PF PID excess load error
• PF Encoder failure (contaminated/detached scale, Encoder Board failure)
• PF Motor failure
• PF drive mechanism overload (paper jam/foreign object)
• Cable disconnection
0xF2 PF PID excess speed error
• PF Encoder failure (contaminated/detached scale, Encoder Board failure)
• Motor driver failure (Main Board failure)
• Tooth skip of the PF Timing Belt
• Improper tension of the PF Timing Belt
0xF3 PF PID reverse error
• PF Encoder failure (contaminated/detached scale, Encoder Board failure)
• Tooth skip of the PF Timing Belt
• Improper tension of the PF Timing Belt
• Paper jam
Table 1-2. Fatal Error List
