Epson WF-5690 User Manual

7. Check the printed pattern to see if there are gaps in the lines.
Print head is clean
Print head needs cleaning
8. Do one of the following:
• If there are no gaps, select Done.
• If there are gaps or the pattern is faint, select Clean the Print Head and continue.
9. Follow the instructions on the screen to clean the print head, check the nozzles, and repeat the
process as necessary.
If you don’t see any improvement after cleaning the print head up to 4 times, leave the product turned on
and wait at least 6 hours. Then try cleaning the print head again. If quality still does not improve, one of
the ink cartridges may be old or damaged and needs to be replaced.
Parent topic: Print Head Nozzle Check
Related concepts
Print Head Cleaning
Related tasks
Removing and Installing Ink Cartridges
Related topics
Loading Paper
Checking the Nozzles Using a Computer Utility
You can check the print head nozzles using a utility on your Windows or Mac computer.
265

Epson WF-5690 Specifications

General

Print Resolution	4800 x 1200 dpi
Automatic Duplex Printing	Yes
Scanner Type	Flatbed, ADF
Scan Resolution	1200 x 2400 dpi
Display	4.3-inch color touchscreen
Functions	Print, copy, scan, fax
Maximum Resolution	4800 x 1200 dpi
Ink Type	DURABrite Ultra pigment ink
Ink Colors	Black, Cyan, Magenta, Yellow
Print Technology	PrecisionCore Inkjet
Print Speed	20 ppm (black), 20 ppm (color)
Connectivity	USB, Ethernet, Wi-Fi, Wi-Fi Direct
Paper Handling	250-sheet input tray
Mobile Printing	Epson Connect, Apple AirPrint, Google Cloud Print
Maximum Paper Size	8.5 x 47.2 inches
Paper Sizes	Letter, Legal, A4, A5, A6
Input Capacity	250 sheets
