Product overview & technical specications
The SpectraPix Lithium Batten contains 224 SMD 5050 RGB LEDs divided into 16 segments. They feature a wide
120° viewing angle and feature a milky, frost effect front screen along with clear front screen to further expand
the versatility of this xture. The internal lithium battery has autonomy of up to 7.5 hours in single colour mode
and up to 16 hours of colour fading and chases, while the charging time is only 4 hours. Onboard features include
colour mixing to create soft washes from its rich colour palette, and chase programs controlled in auto mode or
activated by music. The IR remote and on-board wireless DMX receiver makes for a truly cable free operation and
is W-DMX compatible.
• 224 tri-colour SMD 5050 LEDs (RGB)
• Viewing angle: 120°
• Refresh rate: 10kHz
• DMX channels: 3/3/5/24/48 or 53 selectable
• Wireless control (W-DMX Sweden compatible receiver)
• Static colour, auto, sound active and master/slave mode when
cabled plus built-in programs
• 0-100% dimming
• Variable strobe
• Bracket allows for multiple rigging or oor standing applications
• 4 push button menu with LED display
• Rechargeable battery for wireless applications
• Maximum run time: up to 7.5 hours (single colour), 16 hours
(colour change/fade), 3 hours 45 mins (full on)
• Charging time: 4 hours (max.)
• IEC power input/output
• 3-Pin XLR input/output
• Convection cooled
• Supplied with IR remote
SpectraPix Lithium Batten
Specications
Power consumption 56W
Power supply 110~240V, 50/60Hz
Fuse F3A 250V
Battery 24V 5800mAh
Battery Fuse F3A 250V
Dimensions 90 x 1043 x 60mm
Weight 2.4kg
Order code EQLED058
1013mm 60mm
60mm
1043mm
65mm
90mm
