Equinox Systems SpectraPix Lithium Batten - Component Identification & Package Contents; Component Identification; Package Contents

www.prolight.co.uk SpectraPix Lithium Batten User Manual
4
SPECTRAPIX
LITHIUM BATTEN
IR
CHARGING
INDICATOR
WIRELESS DMX
ON
OFF
POWER
POWER OUTPUT
110-240V~50/60Hz
100%
75%
50%
25%
POWER CONSUMPTION:
56W
POWER INPUT
110-240V~50/60Hz
BATTERY FUSE:
F3A 250V
Technical specications
In the box:
1 x xture with
frosted front screen,
1 x clear front screen,
2 x knobs,
2 x mounting
brackets/feet,
& 1 x power cable
01 02
01 - Bracket tightening knobs
02 - Bracket
03 - IEC power input
04 - Fuse F3A 250V
05 - Earth point
06 - Power switch
07 - 3-Pin XLR input
08 - 3-Pin XLR output
09 - Microphone
10 - Function buttons
11 - LED display
12 - Charging indicator
13 - IR sensor
14 - IEC power output
