-7-
Installation
Outdoor Camera Installation:
Outdoor camera
Bracket
Wall plug
Anti-tamper screw
Installation screws
96
72
After wiring a Power Supply and/or Unlock Module (not included) to the connection
terminal, tension the cable. Fit the cable cover over the connection terminal with the
four screws supplied.
Cable cover
Cable
When locating the outdoor camera, position the camera lens at an average 'head
height' . Fix the bracket to the wall with the screws supplied and locate the outdoor
camera onto the wall bracket. Finally fit the anti-tamper screw.
battery compartment cover
