Erato GP20+ - Board; Table 5.1. Description of the Operating Parameters of the Burners Control Board

Instruction manual for installation and operation of automatic pellet burner “ERATO GP20+”
(Version : 02.02.2010 10:36) p. 28/50
Potentiometer number
Number
of LED
blinking
P1 P2 P3 P4 P5
[-]
Operating period
[seconds]
Index
0 30 1.50 30 45 0
1 45 1.65 60 90 1
2 60 1.82 90 135 2
3 75* 2.18 120 180 3
4 90 2.83 150* 225 4
5 105 3.68 180 270 5
6 120 4.79 210 315 6
7 135 6.22 240 360 7*
8 150 7.46 270 405 8
9 165 8.21 300 450* 9
Table 5.1. Description of the operating parameters of the burner’s control
board.
NOTE : the values, indicated with this symbol “ * ” show the default (factory
preset) values of the operating parameters, which in most cases will guarantee
reliable and effective operation of the burner;
The producer reserves the right to change the specification and/or the default
values of the operating parameters of the unit without prior notice;
NOTES:
• The default values of the operating parameters of the burner are derived at
the following conditions:
o The fuel is wood pellets, with diameter d=6 mm, A category (see
table of wood pellets categories);
