Instruction manual for installation and operation of automatic pellet burner “ERATO GP20+”
(Version : 02.02.2010 10:36) p. 9/50
Parameter Dimension Value
main module kg 18
Weight
fuel transport auger kg 14
main module mm 250 х 570 х 530 Overall dimension of
the unit (WxDxH)
fuel transport auger mm 220x1890x110
Power supply -
1PEN ; 50Hz;
230V;
at nominal load 0.2 A Power consumption
rate
at ignition 4.5 A
Electrical capacity
VA <100 + 1100 (at
ignition process)
Electric protection - IP20
Table 2.2 Dimensions and technical data of automatic pellet burner “ERATO
GP20+”
Parameter Dimension Value
Pellet’s characteristic size mm 6 – 8
MJ/kg >17.2 Recommended fuel net calorific value
kWh/kg >4.7
Wood pellets category
A, AB, B
Ash content % See Table 2.4.
Moisture content % Max. 8 – 10%
Table 2.3 Recommended solid biomass fuel properties – wood pellets
