19
EBP28
Getting Started . . .
Before you start
3. Align the tabs on the other end of the S-shaped tube (17) with the slots on the
blower outlet (1). Insert the S-shaped tube (17) into the blower outlet (1) all the way
until it clicks into place (Fig. 2).
2
17
1
NOTE: To detach the S-shaped tube (17) from the blower outlet (1), use the
multi-tool (20) to depress the red locking lever, and pull the S-shape tube (17)
(Fig. 3).
3
Locking lever
20
1
