Product description
Part index
The index below refers to Fig. 1 on page 4.
1. Sliding slot
2. Power cord with plug
3. Charger status indicator
Technical data
Charger model EBFC12-Li EBC12-Li
> Rated input : 100-240 V~, 50/60 Hz, 90 W 100-240 V~, 50/60 Hz, 60 W
> Rated output : 12 V d.c., 6 A 12 V d.c., 4 A
> Protection class : II
> Weight : approx. 0.6 kg
For charging 12V Li-Ion battery packs as below:
> Battery pack model : EHPB12-Li-6 EHPB12-Li-3
> Battery capacity : 6.0 Ah 3.0 Ah
> Battery cells : 3.6 V x 6 pcs 3.6 V x 3 pcs
> Approx. Charging time
(EBFC12-Li /
EBC12-Li) : 80min/120min 45min/60min
> Ambient temperature
range : 0 - 45 °C
Rating label explanation
EBC12-Li and EBFC12-Li = Model number
E = Erbauer
BC = Battery Charger
BFC = Battery Fast Charger
12 = For 12V battery
Li = Li-Ion
