UNPACKING
Unpack all parts and lay them on a at, stable surface.
• Remove all packing materials and shipping devices, if applicable.
• Make sure the delivery contents are complete and free of any damage. If you nd that parts
are missing or show damage do not use the product but contact your dealer. Using an
incomplete or damaged product represents a hazard to people and property.
• Ensure that you have all the accessories and tools needed for assembly and operation. This
also includes suitable personal protective equipment
WARNING!
The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts! There is a
danger of choking and suffocation!
03
ASSEMBLING THE MACHINE
AUXILIARY HANDLE ( A )
For all work with the machine, the auxiliary handle (2) must be mounted. Screw the
auxiliary handle (2) in one of the mounting threads (4) of the machine head depending on
the working method.
WARNING!
Do not make any alterations to the auxiliary handle. Do not
continue to use an auxiliary handle if it is damaged.
MOUNTING THE GRINDING/CUTTING WHEELS
Before any work on the machine itself, remove the mains plug from socket outlet.
Grinding and cutting wheels become very hot while working, do not touch until they have
cooled.
1.
Spindle lock button
Clean the grinder spindle and all parts to be mounted. For clamping and loosening the
wheels, lock the grinder spindle (12) with the spindle lock button (3).
WARNING!
Actuate the spindle lock button (3) only when the grinder
spindle is at a standstill!
2.
Adjustable outer ange clamping ( B1, B2 )
The outer ange (11) should be adjusted to suit different wheel thickness. For thinner
cutting or diamond wheels the raised part of the outer ange is tted facing away from
