10. DRILLING
When drilling into a hard smooth surface, use a
center punch to mark the desired hole location. This
will prevent the drill bit from slipping off center as
the hole is started. Hold the tool firmly and place
the tip of the bit at the point to be drilled. Depress
the switch trigger to start the tool. Move the drill bit
into the workpiece, applying only enough pressure
to keep the bit cutting. Do not force or apply side
pressure to elongate a hole.
If you want to activate the drill function (For drilling
metal wood or plastic), turn the torque adjustment
ring on the drill position. If you want to activate the
impact function(For masonry or concrete), turn the
torque adjustment ring on the hammer position.
TUNGSTEN carbide drill bits should
always be used for concrete and
masonry. When drilling in metal, only use
HSS drill bits in good condition. Always use a
magnetic bit holder (not included) when using
short screwdriver bits. When screw-driving,
apply a small quantity of liquid soap or similar
to the screw threads to ease insertion.
11. DISPOSAL OF AN EXHAUSTED BATTERY
PACK
To preserve natural resources, please recycle
or dispose of the battery pack properly. This
battery pack contains Lithium batteries.
Consult your local waste authority for information
regarding available recycling and/or disposal
options. Discharge your battery pack by operating
your drill, then remove the battery pack from the drill
housing and cover the battery pack connections
with heavy-duty adhesive tape to prevent short
circuit and energy discharge. Do not attempt to
open or remove any of the components.
12. OVERLOAD PROTECTION
When overloaded, the motor comes to a stop.
Relieve the load on the machine immediately and
allow cooling for approx. 30 seconds at the highest
no-load speed.
13. TEMPERATURE DEPENDENT OVERLOAD
PROTECTION
When using as intended for the power tool cannot
