Ercolina Super Bender 060 - Before you Begin; General Identification of Parts

-5-
Before you Begin
Inspect machine to be sure following equipment arrived and no damage occurred during shipment.
060
®
Super Bender
®
and Standard accessories
060A Super Bender
®
model 060
®
050A 40mm hex shaft
050B 50mm hex shaft (mounted on machine)
050D Support bracket for counterbending die
050G Hand wheel
050H Foot Pedal
General Identication of Parts
1. Foot pedal switch 7. Counterbending die
2. Emergency stop 8. Counterbend die vise
3. Programming 9. Counterbend die hand wheel
4. Control panel with display 10. Transportation handle
5. Center former die 11. Access Panel
6. Hex shaft
11 - Access panel
10 - Transportation
handle
9 - Counterbend die
hand wheel
8 - Counterbend
die vise
7 - Counterbending
Die
6 - Hex
shaft
5 - Center
former die
4 - Control panel
with display
3 - Programming
2 - Emergency
stop button
1 - Foot pedal switch
