Cleaning and maintenance
10/2011 1007368-04 Operating instructions – 53
Replacing the lamps: see page 45.
Replace the starter: see page 46.
Makrolon tubes (if fitted): see page 46.
The assembly is the same process in reverse order.
5.15 Cleaning or replacing the front panel
accent lighting
– From the front reach under the front panel and remove the effect lamps.
Replacing the lamps: see page 45.
Replace the starter: see page 46.
Makrolon tubes (if fitted): see page 46.
The assembly is the same process in reverse order.
5.16 Cleaning or replacing ambient light
(cabin lighting)
2 effect lamps are located on the rear side of the canopy.
– If necessary, cover the canopy in order to prevent the paint from being
scratched.
– Remove the lamps on the rear of the canopy.
Replacing the lamps: see page 45.
Replace the starter: see page 46.
Makrolon tubes (if fitted): see page 46.
The assembly is the same process in reverse order.
