ergoline Vertical series - ROOF AND CYLINDER FITTING; Attaching the Unit Roof and Cables

Ergoline Vertical
User manual
Seite 14 von 29
Put the roof on the 4 panels; take care about cables that have to pass through the right holes of the roof.
Insert M6 nuts on rear side without fixing them at
all.
Insert plastic cylinders on the top side of panel 1 and 6 (doors);
