ergoline Vertical series - 2 Equipment Data

Ergoline Vertical
User manual
Seite 4 von 29
EQUIPMENT DATA
Model
Ergoline Vertical
Voltage supply
400 V ac
Phase
3 + N + PE
Frequency
50 Hz
Amperage
20 A
lamps
48x 180W 2mt
Unit dimensions
(door closed)
Length x width x height
(1200 x 1000 x 2350) mm
Unit dimensions
(door opened)
Length x width x height
(1290 x 1265 x 2350) mm
H = 2360mm
H1 = 2660mm
H2 = 2330mm
H3 = 65mm
H9 = 3000mm
D = 500mm
B3 = 525mm
TK = 2380mm
BK = 1630mm
TK = 2600mm
