ergoline Vertical series - ELECTRICAL WIRING CONNECTIONS; Connecting Connectors and Power Supply

Ergoline Vertical
User manual
Seite 16 von 29
Connect white plastic connectors with the same
number.
Connect the power supply cable to the main filter,
then push the cable through the channel on panel
4 as shown in following pictures;
the cable comes out from the bottom side.
Repeat the same operation with the 6-pole cable for connecting to external timer if needed;
