Move and block the stop slide S2 to the desired distance. The value of
offsetting is displayed in area L Fig. 7.
Fig. 7.
6.3 BENDING
In order to start the bending operation, go the BODY menu and equip the body with a
punch and the measuring insert SH 401PLC - E.After a mandrel is installed, a window
will appear where you will have to define the reference points of the measurement bars
(Fig. 8).
Fig.8 Fig.9
Fig.10 Fig.11
