CONFIGURATION PARAMETERS
Notes:
1) In the following pages we will describe all the
parameters of the instrument but the instrument
will show only the parameters related with the
specific hardware and in accordance with the
specific instrument configuration (i.e. setting
Ser1 = OFF (not used), all the parameters
related with serial interface will not be
displayed).
2) During configuration mode, the lower display
shows the mnemonic code of the selected
parameter while the upper display shows the
value or the status assigned to the selected
parameter.
dF.CndF.Cn
dF.CndF.Cn
dF.Cn - Load default configuration data
This parameter is skipped in monitor configuration
parameter mode.
OFF = No default data loading
tb.1 = Load default data from European table
(TB1)
tb.2 = Load default data from American table
(TB2)
SEr1SEr1
SEr1SEr1
SEr1 = Serial interface protocol
OFF = No serial interface
ero = Polling/selecting ERO
nbUs = Modbus
jbUs = Jbus
NOTE: the "serial comunication" and the "logic
input" options are mutually exclusive and
selectable by a jumper setting.
ser2ser2
ser2ser2
ser2 = Serial link device address
Not available when SEr1 = OFF
From 1 to 95 for ERO protocol
From 1 to 255 for all the other protocols
NOTE: the electrical characteristic of the RS 485
serial interface will allow the connection of 31
devices maximum.
ser3ser3
ser3ser3
ser3 = Baude rate for serial link
Not available when SEr1 = OFF
From 600 to 19200 baud.
NOTE: 19200 baud is shown on display as 19.2.
ser4ser4
ser4ser4
ser4 = Byte format for serial link
Not available when SEr1 = OFF
7e = 7 bits + even parity (For ERO protocol only)
7O = 7 bits + odd parity (For ERO protocol only)
8E = 8 bits + even parity
8O = 8 bits + odd parity
8 = 8 bits without parity
P1 - Input type and standard range
0 = TC type L range 0 / +400.0 °C
1 = TC type L range 0 / +900 °C
2 = TC type J range-100.0 / +400.0 °C
3 = TC type J range -100 / +1000 °C
4 = TC type K range-100.0 / +400.0 °C
5 = TC type K range -100 / +1370 °C
6 = TC type T range -199.9 / +400.0 °C
7 = TC type N range -100 / +1400 °C
8 = TC type R range 0 / +1760 °C
9 = TC type S range 0 / +1760 °C
10 = TC type B range 0 / +1820 °C
13 = mV Linear range 0 / 60 mV
14 = mV Linear range 12 / 60 mV
15 = mA Linear range 0 / 20 mA
16 = mA Linear range 4 / 20 mA
17 = V Linear range 0 / 5 V
18 = V Linear range 1 / 5 V
19 = V Linear range 0 / 10 V
20 = V Linear range 2 / 10 V
