Figure 2.3 CONTROL CONNECTIONS
OUTPUT RECEPTACLE 2.4
SW
POWER
SWITCH
63A
600V
CKT. BREAKERS,
10A 32VDC, 250VAC
SECTION 2 INSTALLATION
+
-
