ESAB 453cc - Bill of Materials

29
1 954838 1 LABEL SUBARC STICK
2 954839 1 LABEL MIG
3 836121 1 PCB DIGITAL METER PCB2
4 836173 1 BLADE FAN 14"
5 838127 1 PCB CONTROL PCB1
838128 1 CONTROL PCB
6 8634515 2 SW TGGL SPDT 2 POS 15A 125V S2,3
7 8672065 6 STRAP TERMINAL
8 8678025 2 TERM AY
9 8950122 2 CKT BREAKER 10A 32VDC 250VAC CB1,2
10 8950219 1 RELIEF STRAIN 2.00
11 8950711 2 SW THERMAL 194F TS1,3
12 8950768 1 DIODE FWD 300V 300A D1
13 836107 1 SW PWR DISC 63A 600V S1
8950945 1 SW PWR DISC 100A 600V S1
14 8951474 2 SW SEAL BLACK
15 8954008 1 LABEL DANGER HIGH VOLTAGE
16 82062334 1 MOTOR FAN 1/3 HP 1625RPM M1
17 80558001024 3 SCR ASSY SCR1-6
18 34149 1 CLIP ANNEALED
19 34916 3 BUSBAR TAB
20 36091 1 BOARD INPUT TERMINAL 230/460V TB1
136110 1 BOARD INPUT TERMINAL 230/460V/575 TB1
32236 1 BOARD INPUT TERMINAL 220/400V TB1
21 36092 1 CABLE DIGITAL METER PCB P10
22 36635 4 CLIP SKID
23 37861GY 1 BASE
24 37862GY 1 PANEL FRONT BOTTOM
25 37863YL 1 PANEL RIGHT SIDE
26 37864YL 1 PANEL LEFT SIDE
27 37865 1 CONTROL PANEL
28 37867GY 1 PANEL REAR
29 37868 1 BRIDGE BUSBAR
30 37869 1 HIGH TAP INDUCTOR BUSBAR
31 37870 1 LOW TAP INDUCTOR BUSBAR
32 0558001037 1 SHUNT SH
33 37872 2 INSULATOR KYDEX
34 836430 1 XFMR MAIN 230/460 453CC T1
836626 1 XFMR MAIN 230/460/575V 453CC T1
836622 1 XFMR MAIN 220/400 453CC T1
836610 1 XFMR MAIN 230/460 553CC T1
836684 1 XFMR MAIN 230/460/575V 553CC1T1
836687 1 XFMR MAIN 220/400 553CC1T1
35 C-836426 1 INDUCTOR L1
36 0558001568 1 SCHEMATIC DIAG 453CC/553CC 50/60HZ
37 0558001569 1 WIRING DIAG PRI 3 PH AFRAME 453CC/553CC
38 0558001570 1 WIRING DIAG SECONDARY 453CC/553CC 50/60HZ
39 0558001329 1 KIT WIRE PRI 453CC
0558001879 1 KIT WIRE PRIMARY 553CC
40 0558001330 1 KIT WIRE SEC 453CC/553CC
SECTION 6 REPLACEMENT PARTS
Bill of Materials
453cc/553cc DC Welding Power Source
ITEM PART OR
NO. CODE NO. QTY. DESCRIPTION SYMBOL
