SECTION 6 REPLACEMENT PARTS
Bill of Materials
453cc/553cc DC Welding Power Source
ITEM PART OR
NO. CODE NO. QTY. DESCRIPTION SYMBOL
133 99512240 1 LABEL CAUTION LIFT EYE
134 99512558 2 BRACKET RESISTOR #18
135 0558001010 1 TERMINAL BLOCK 3 POS TB3
136 0558001011 1 BOX PCB GRAY
137 0558001012 3 PLUG HOUSING 2 POS
138 0558001014 3 SEAL WIRE 2 POS
139 0558001015 3 SEAL INTER
140 0558001016 1 CAP 9 POS J6
141 0558001018 1 INSULATOR STAND OFF
142 0558001019 1 KNOB 1.57 DIA
143 0558001032GY 1 PANEL FRONT TOP
144 0558001038 1 INSULATOR
145 180W66 AR TYWRAP LARGE
146 180W68 AR TYWRAP SMALL
147 36043GY 1 BRACKET FAN
148 36048GY 4 LEG AFRAME
149 36049GY 1 BAIL LIFTING
150 36070GY 1 BRACKET TERMINAL BOARD MTG
151 36642GY 1 BAFFLE
36140GY 1 BAFFLE
152 37902GY 1 BLANKING PLATE
153 0558001818 1 KNOB 01.37 A
154 37866YL 1 PANEL TOP
155 90861100 AR TUBING INSULATING VINYL 105' C RATING 9" LG
156 90863005 AR TUBING HEAT SHRINKABLE 6" LG
157 838100 1 CE FILTER ASSY FN1
159 952223 3 STAND OFF 1/4-20 X .75
160 0558001331G 1 HINGE ACCESS
161 0558001332G 1 PANEL ACCESS GRAY
162 A-954864 1 LABEL THREE PHASE
166 A-892W64 1 POT LIN 100K 2W R2
167 10981006 AR SOLDER 60/40 ROSIN
