46
SECTION 7 REPLACEMENT PARTS
Bill of Materials
653cvcc DC Welding Power Source
ITEM PART OR
NO. CODE NO. QTY. DESCRIPTION SYMBOL
1 954838 1 LABEL SUBARC STICK
2 954839 1 LABEL MIG
3 36121 1 PCB DIGITAL METER PCB2
4 36173 1 BLADE FAN 14"
5 38130 1 PCB CONTROL PCB1
6 634515 3 SW TGGL SPDT 2 POS 15A 125V S2,3,4
7 672065 6 STRAP TERMINAL, VOLTAGE CHANGELINE
8 678025 3 TERM AY OUTPUT
9 950122 2 CKT BREAKER 10A 32VDC 250VAC CB1,2
10 950219 1 RELIEF STRAIN 2.00
11 950711 3 SW THERMAL 194FT S2,3,4
12 950768 2 DIODE FWD 300V 300A D1,2
13 950945 1 SW PWR DISC 100A 600V S1
14 951474 3 SW SEAL BLACK
15 954008 1 LABEL DANGER HIGH VOLTAGE
16 2062334 1 MOTOR FAN 1/3 HP 1625RPM M1
17 0558001024 3 SCR ASSY
18 34149 1 CLIP ANNEALED
20 36110 1 BOARD INPUT TERMINAL 230/460V/575
21 36092 1 CABLE DIGITAL METER PCB P10
23 37861M 1 BASE
24 37862M 1 PANEL FRONT BOTTOM
25 0558001369 1 PANEL RIGHT SIDE ENV
26 0558001370 1 PANEL LEFT SIDE ENV
27 0558001378 1 CONTROL PANEL BLACK
28 37867M 1 PANEL REAR
30 37869 1 HIGH TAP INDUCTOR BUSBAR
31 37870 1 LOW TAP INDUCTOR BUSBAR
32 37871 1 SHUNT
33 37872 2 INSULATOR KYDEX
34 37890 1 XFMR MAIN 230/460/575V T1
35 37883 1 INDUCTOR L1
36 37907 1 SCHEMATIC DIAG 653 CVCC
37 37908 1 WIRING DIAG SEC 653 CVCC
38 0558001044 1 WIRING DIAG PRI 3 PH AFRAME
43 647361 1 TERMINAL LUG
44 672786 1 BOLT EYE .75-10 X 2.00
45 950167 1 GROMMET RUB 1.12 ID X 1.50 GD X .06 W
46 950905 1 TERM IL/M .250 TS X 14-16 AWG
47 951504 1 PLUG HOUSING 15 POS J5
48 0558001013 1 CAP HOUSING 2 POSITION
49 952067 1 CONNECTOR 20 AWG 3 PIN P1
50 952068 1 MTA-156 COVER 3 PIN
51 952070 1 CONNECTOR 20 AWG 7 PIN P5
52 952071 1 MTA-156 COVER 7 PIN
53 952072 3 CONNECTOR 20 AWG 12 PIN P3,4,7
54 952073 1 TERM BLOCK 12 POS
57 952209 1 PANEL RECEPTACLE 19 PIN F J1
