ESAB A2 TFE1 - Page 40

-- 4 0 --
dha4r11a
Item
no.
Qty. Ordering no. Denomination Notes
0147 639 882 Straighte ner right
1 1 0156 449 001 Clamp
4 1 0215 503 601 Insulating collar
5 0156 530 001 Clamp half
6 2 0212 900 010 Fixing screw
7 4 0215 201 209 O-- ring
8 2 0218 400 801 Arm (pressure roller)
9 1 0218 810 181 Insulated hand wheel top
10 1 0218 810 182 Insulated hand wheel bottom
11 3 0332 408 001 Stub shaft
13 3 0153 148 880 Roller
14 1 0415 498 001 Top roller shield
15 2 0212 902 601 Spacing screw
16 1 0415 499 001 Low roller shield
28 1 0156 531 001 Clamp half
29 1 0456 504 881 Arc welding cable
