ESAB Arc 151i - 3 Technical Data

© ESAB AB 2008
- 7 -
bh32d1e
3 TECHNICAL DATA
Arc 151i Arc 201i
Mains voltage 230 V, 1  50/60 Hz 230 V, 1  50/60 Hz
Primary current
I
max
TIG
I
max
MMA
13.8 A
21.3 A
24.1 A
24.9 A
Mains supply Z
max
0.35 ohm Z
max
0.30 ohm
No-load power 30 W 30 W
Voltage/current range, MMA
A31
8 A /20 V - 150 A /26 V -
A33 4 A /20 V - 150 A /26 V 4 A /20 V - 170 A /26.8 V
Voltage/current range TIG 3 - 150 A 3 - 220 A
Permissible load at MMA
25% duty cycle
60% duty cycle
100% duty cycle
150 A / 26.0 V
100 A / 24.0 V
90 A / 23.6 V
170 A / 26.8 V
130 A / 25.2 V
110 A / 24.4 V
Permissible load at TIG
20% duty cycle
25% duty cycle
60% duty cycle
100% duty cycle
-
150 A / 16.0 V
120 A / 14.8 V
110 A / 14.4 V
220 A / 18.8 V
-
150 A / 16.0 V
140 A / 15.6 V
Power factor at maximum current 0.99 0.99
Efficiency at maximum current 80% 81%
Open-circuit voltage
A31 without VRD function
1)
A33 VRD function deactivated
2)
VRD function activated
2)
58 - 72 V
55 - 60 V
< 35 V
-
55 - 60 V
< 35 V
Operating temperature -10° C - +40° C -10° C - +40° C
Transportation temperature -20° C - +55° C -20° C - +55° C
Constant A-weighted sound pressure < 70 dB < 70 dB
Dimensions, l x b x h 418 x 188 x 208 mm 418 x 188 x 208 mm
Weight
with A31
with A33
7.9 kg
8.1 kg
-
8.3 kg
Enclosure class IP 23 IP 23
Application class
1) Valid for power sources without VRD specification on the rating plate.
2) Valid for power sources with VRD specification on the rating plate. The VRD function is explained in
the instruction manual for the control panel.
Mains supply, Z
max
Maximum permissible line impedance of the network in accordance with IEC 61000-3-11.
Duty cycle
The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or cut at
a certain load without overloading. The duty cycle is valid for 40° C.
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid
objects or water. Equipment marked IP23 is designed for indoor and outdoor use.
Application class
The symbol indicates that the power source is designed for use in areas with increased
electrical hazard.
GB
