- 6 -
bm44d1ea
4 TECHNICAL DATA
Feed L3004
Power supply 42 V 50-60 Hz
Power requirement 180 VA
Motor current I
max
3.5 A
Wire feed speed 0.8 - 25.0 m/min
Gun connection EURO
Max. diameter wire bobbin 300 mm (*440 mm)
Wire dimension
Fe
Ss
Al
Cored wire
0.6 - 1.2 mm
0.6 - 1.2 mm
1.0 - 1.2 mm
0.8 - 1.2 mm
Weight 15 kg
Dimensions (l x w x h) 690 x 275 x 420 mm
Operating temperature -10 to +40° C
Shielding gas
max pressure
All types intended for MIG/MAG welding
0.5 MPa (5 bar)
Type of cooling
max pressure
50% water / 50% mono-ethylen glycol
0.5 MPa (5 bar)
Maximum permissible load at
60% duty cycle 365 A
Enclosure class
with sealed bobbin holder
without sealed bobbin holder
IP23
IP2X
* Accessories, see page 18.
Duty cycle
The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or cut at
a certain load without overloading. The duty cycle is valid for 40° C.
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid
objects or water. Equipment marked IP23 is designed for indoor and outdoor use.
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid
objects or water. Apparatus marked IP2X are intended for indoor use.
5 INSTALLATION
The installation must be executed by a professional.
