S0740 800 210/E101102/P18
- 10 -
ck10i1
INSTRUCTIONS
This chapter is an extract from the instruction manual for the COOL1.
SAFETY
CAUTION!
Read and understand the instruction manual before
installing or operating.
INSTALLATION
The installation must be executed by a professional.
Location
Position the cooling unit such that its air inlets and outlets are not obstructed.
Power supply and control
COOL1 is powered and controlled from the power source via socket connector XS4 in the
bottom of the power source. The plug connector 5XP1 on top of the cooler is connected to
XS4.
Installing to welding equipment
See assembly instructions on page 11.
