S0740 800 210/E101102/P18
- 14 -
ck10i1
Inspection and cleaning
WARNING!
The mains supply must be disconnected before cleaning!
Dust, grinding swarf etc The air stream through the cooling unit carries particles that
become trapped in the cooling element, particularly in dirty working environments. This
results in reduced cooling capacity. For this reason, blow clean using compressed air at
regular intervals.
The coolant system - The recommended coolant must be used in the system otherwise
clumps can be created that block the pump , water connections or elements. Flushing can
only be performed via red water connection. Then drain the tank manually, i.e. empty via
the tank's filing hole.
Filling the coolant
ESAB's coolant is recommended for use. See accessories in instruction manual.
S Fill with coolant.
(The fluid level must not exceed the
upper marking but neither must it be
below the lower marking)
Note! Coolant must be topped up if
connecting a welding gun or coolant
hoses that are 5 metres in length or
longer. When adjusting the water level by
topping up, the coolant hoses do not
need to be disconnected.
The temperature of the coolant must not exceed 70° C
CAUTION!
The coolant must be handled as chemical waste.
