ESAB EC 1000 - 3 Technical Data

3 TECHNICAL DATA
0445 030 101
- 8 -
© ESAB AB 2017
3 TECHNICAL DATA
EC1000
Power consumption 24 V DC, 3.0A
Cooling power 0.9 kW
Noise
(Constant sound pressure when idling)
< 70 dB(A)
Coolant ESAB's ready mixed coolant, see the
"ACCESSORIES" chapter in the instruction
manual.
Coolant quantity 1.5 l
Maximum water flow 1.8 l/min
Max pressure lift for torch Q
max
4.5 bar (65psi)
Operating temperature -10°C to +40°C (+14°Fto +104°F)
Transportation temperature -20°C to +55°C (-4°Fto +131°F)
Dimensions (l × w × h) 540 × 200 × 170 mm
(21.26×7.874×6.693in)
Weight empty 8 kg (17.6lb)
Enclosure class IP23
The cooling unit is rated 300 A at 40% duty cycle at 25°C (77°F) ambient temperature.
Duty cycle
The duty cycle refers to the time as a percentage of a ten-minute period that you can weld or
cut at a certain load without overloading. The duty cycle is valid for 40°C/104°F, or below.
Enclosure class
The IP code indicates the enclosure class, i.e. the degree of protection against penetration
by solid objects or water.
Equipment marked IP23 is intended for indoor and outdoor use.
