3 INTRODUCTION
ESABMig C280 & ESABMig C340 are step controlled power sources in a compact
design, intended for welding with solid steel, stainless steel or aluminium wire as well
as tubular wire with or without shielding gas.
The possibility of welding with homogeneous wire/shielding gas and welding with
gasless tubular wire is obtained by switching the + and − connections on the
switching terminal above the wire feed unit.
ESAB’s accessories for the product can be found on page 176.
3.1 Equipment
3.1.1 ESABMig C280
The power source is supplied with:
S Welding gun PSF 250 − 3m (ESABMig C280 4WD − 4,5m)
S Return cable 3,5m with return clamp (ESABMig C280 4WD − 5m)
S Shelf for gas cylinder
S Instruction manual
3.1.2 ESABMig C340
The power source is supplied with:
S Welding gun PSF 305 − 3m (ESABMig C340 4WD − 4,5m)
S Return cable 3,5m with return clamp (ESABMig C340 4WD − 5m)
S Shelf for gas cylinder
S Instruction manual
4 TECHNICAL DATA
4.1 ESABMig C280
Voltage 400−415 V, 3∼ 50/60 Hz 230/400−415/500V3∼50Hz
230/440−460V, 3∼60Hz
Permissible load at
100% duty cycle 150 A/22 V 150 A/22 V
60 % duty cycle 190 A/24 V 190 A/24 V
30 % duty cycle 280 A/28 V 280 A/28 V
Setting range (DC) 30A/15V−280A/28V 30A/15V−280A/28V
Open circuit voltage 15−38 V 15−38 V
Open circuit power 190 W 190 W
Efficiency 69% 69%
Power factor 0.97 0.97
Control voltage 42 V, 50/60 Hz 42 V, 50/60 Hz
Wire feed speed 1,9 − 19m/min 1,9 − 19m/min
GB
