SECTION 7 Replacement Parts
ESP 600C Plasma Power Source
7-9
Item No Qty Part Number Description Circuit Symbol
1 3 35895 Kit Wire 600C 400V
C60,61,62,
R55-57
3 4 951491 Contactor 3 pole 90A K2,K1a,1b,1c
4 2 2046333 Fuse Slo-Blo 15A 600V F1,2
5 2 672772 Capacitor 10 µf 370V C25,26,34-36
6 2 17280210 Resistor 1K ohms 100W R10,11,28-31
7 3 17280010 Resistor 10 ohms 100W R25,26,27
8 1 950703 RECT SIL Forward 85A D34
9 1 950704 RECT SIL Reverse 85A D33
10 35710 Inductor (REF) L1,2
11 1 952002 Core, Saturable Amorphos
