SECTION 7 Replacement Parts
ESP 600C Plasma Power Source
7-11
Item No Qty Part Number Description Circuit Symbol
1 2 38030 PCB IGBT Driver PCB2,3
2 6 17750051 Resistor 10ohm 50W Noninductive R4-9
3 6 951828 Capacitor .033 µf 630V C13-18
4 15 951635 Capacitor 1900 µf 450V C1-12,29,32,33
5 3 951085 Switch Thermal 176 DEG F TS4-6
6 4 35779 Kit Wire ESP Control 460/575V
7 6 0558001020 Module Diode Dual 100A 600V D1-6
8 2 pr 951951 IGBT Matched Pair 600A 600V
9
10 4 950704 RECT SIL Reverse 85A
11 5 672772 Capacitor 10 µf 370V C25,26,34,35,36
12 5 17300008 Resistor 8 ohm 300W R12-15,24
13 2 0558002348 Transducer Current TD1,2
14 1 951282 Shunt 100mV 500A SH1
15 4 951998 Capacitor .27 µf 1200 VDC C19-22
16 4 951996 Module Dual Diode Rectifier 600V 30A D19,22
17 2 2046333 Fuse Slo-Blo 15A 600V F3,4
18
19 2 951802 Capacitor 2900 µf 450V C27,28
20 1 950255 Capacitor 60 µf 370V C30
21 2 2062357 Fuse Slo-Blo 30A 250V F5,7
22 1 951527 Fuse 15A F6
23 1 673458 Contactor 3 pole 40A K4
24 2 952103 Fuse holder 60A
25 4 951199 Core Saturable
26 6 952002 Core Saturable Amorphous
27 2 0558002435 Capacitor 3100 µf 450V C27,28
