ASSEMBLING
The complete Installation should consist the following instruments.
Description
Type
Quantity
1.
Welding Power Source
MIGMATIC 250 Power
Source
1
2.
Wire Feeder
MIGMATIC WIRE FEEDER
with accessories
1
3.
Welding Torch
PSF 250
1
4.
CO
2
Regulator cum Flowmeter or
CO
2
Regulator with Flowmeter
1
5.
CO
2
Heater Core
1
ACCESSORIES LIST FOR MIGMATIC 250 MIG/MAG WELDING POWER SOURCES
Fuse, element 3A
2 piece
Fuse, element 8A
1 piece
Instruction Manual
1 piece
RATING OF MIGMATIC 250 MIG/MAG WELDING POWER SOURCE
Characteristics
Constant Potential Type
Input
Supply Voltage phase & frequency
3 phase, 415 V ±10 %, 50 Hz
Maximum Input Current
13 Amps
Maximum Rating
9.5 KVA at 60% duty cycle
Output
Output current range
40-250 Amps
Max. Output current at 60% Duty Cycle
250 Amps
Max. Output Current at 100% Duty Cycle
190 Amps
Open circuit voltage control
16-34 volts DC
Type of Welding Voltage Control
In 10 Steps single Knob control
Welding time
0.2-2 Sec.
Interval time
0.2-2 Sec.
Class of Insulation
Class ‘H’
Cooling
Forced Air Cooled
Approximate dimension (LXWXH) in mm
620*390*580
Weight (Approximate)
78 kg.
