23
SECTION 3 INSTALLATION
3.0 INSTALLATION
3.1 LOCATION
Several factors should be considered when selecting an installation site. Adequate ventilation is necessary to provide cool-
ing, and the amount of dirt and dust to which the machine is exposed should be minimized. There should be at least 18
inches of unrestricted space between the machine’s side and rear panels and the nearest obstruction to provide freedom
of air movement through the power source.
The installation site should permit easy removal of the machine’s outer enclosure for maintenance. Installing or placing any
type of ltering device will restrict the volume of intake air, thus subjecting the internal components to overheating. War-
ranty is void if any type of ltering device is used.
Figure 2 - Dimensions
32”
42”
20”
