SECTION 4 OPERATION
Digital Meters
Amps/Volts/WFS
Power “ON”
Lamp
Temperature
Lamp
Fault
Lamp
WFS - IPM
Lamp
Amps
Lamp
Preset
Button
Weld Process
Switch
Voltage Set - MIG
Current Set - STICK/TIG
Wire Feed
Speed Trim
IPM
Figure 12 - Control Panel
Main Power
Switch
Spool Gun Control Module
(Optional,
blank panel shown)
Remote Control Module
(Optional,
blank panel shown)
Mig Gun
EURO
Connection
Positive Output
Connection
Negative Output
Connection
Polarity Switching
Connector
Figure 13 - Front Panel
