QTY. ITEM CIRCUIT
No. REQ. NO. DESCRIPTION SYMBOL
40 1 948258 SPINDLE MOLDED (SEE FIGURE 28)
41 1 0558002543M REAR COVER
42 1 0558003076 TRANSISTOR REPLACEMENT KIT IGBT MATCHED PAIR 600V - 300A Q1-2
43 1 38186 PCB ASSY. DRIVER PCB3
44 1 0558001893 POWER CABLE 208/230V
1 0558002081 POWER CABLE 230/460/575V
45 1 0558001696M CYLINDER TRAY
46 1 951634 SOLENOID 24 SOL1
47 1 0558002556 INDUCTOR L1
48 1 0558002558 DRIVE MOTOR M2
49 1 0558001339 COMPACT 4 ROLL WDS
50 3 0558001534 CAPACITORS C1,2,3
51 1 -- INDUCTANCE CONTROL (OPTIONAL)
52 1 -- BURNBACK CONTROL MODULE (OPTIONAL)
Figure 27 - Inside Right & Rear View of Multimaster 260 (cont.)
SECTION 6 REPLACEMENT PARTS
