Escea DF700 - Flue Configuration (More than 4 m)

B
A C D E F G SERVICE
18
C3 Installing the Horizontal Powerflue
Note: The appliance is designed only to operate using
the approved flexible or PolyPro flue supplied by
Escea. Other brands of flue may not fit, and this will
aect the appliance warranty.
The Horizontal Powerflue Wall Terminal must be
installed in the correct orientation. This allows for the
correct operation of the flue system and prevents the
ingress of rain.
The Horizontal Powerflue Wall Terminal must be
weather-tight when installation is complete to prevent
damage to the dwelling. It must be installed by a
suitably qualified person.
For flexible aluminium flue, access to the powerflue
from the outside must be provided for servicing, and
this should be taken into consideration when installing in tall buildings.
For PolyPro flue installations, internal and external access is required.
