ESM F7F Tigercat - Elevator and Rudder Installation; Wing Installation and Engine Mount

A = A"
B = B"
A
A"
B"
B
Drill 4.2mm holes at the place
of main wing.
Install the wing to the fuselage
with 4mm screws as shown in
the diagrams below.
135 mm
In case of 2-cycle & 4-cycle engine.
Washer (4x8mm)
Washer (4x8mm)
Washer (4x8mm)
Screw (4x35mm)
Screw (4x25mm)
Nut (4mm)
Spring Washer (4mm)
4mm
5.2mm
Blind Nut
8
Blind Nut (4mm)
8
Blind Nut (4mm)
2
Engine mount (68x105mm)
Linkage Stopper
8
8
24
8
Washer(4x8mm)
Screw (4x35mm)
Spring Washer (4mm)
Nut (4mm)
4
8
Screw (4x25mm)
4
Plastic tube (2x430mm)
Fuel tank (448cc)
2
The sketch map when the main wing install completion.
The front view when the engine install completion.
The side view when the engine install completion.
Drill four holes at the diameters as show
for engine mount.
Assemble the engine as the illustration below.
22
23
24
25
26
5
Accessory list for the coming installation steps.
AILERON
FLAP
AILERON
30mm
FLAP
20mm
20mm
Side View
Top view
Side View
25mm
25mm
RUDDER
Top view
Position for
right diagram.
ELEVATOR
Side View
20mm
20mm
117mm
Switch
Air tank
Rudder servo
Adjustment.
Adjustment.
Adjustment.
Push the hatch thimble to front when assemble
the canopy to fuselage.
Mount the receiver and the battery into the fuselage.
Assemble the servoe of rudder,switch in the fuselage.
The centre of the Gravity.
83
84
85
86
87
16
82
